Mastering the ASP.NET Core API Lifecycle: A Key to Scalable and Robust Applications

Understanding the lifecycle of an application is crucial to gaining a complete perspective on its key processes. This knowledge aids in software design and architecture, bug fixing, implementing new features, error handling, and comprehending the application as a whole.

When it comes to ASP.NET Core applications, specifically APIs, the lifecycle is well-defined and follows a predictable pattern. While each application may have its specificities, they generally adhere to a common flow. Let’s take a look at this flow:

Lifecycle Overview:

1. Application Start
2. Request Initialization
3. Request Handling by Middleware Pipeline
4. Routing
5. Action Execution
6. Response Generation
7. Middleware Post-Processing
8. End Request
9. Application Shutdown

Key Lifecycle Stages

1. Application Start

In ASP.NET Core applications, the Program.cs and Startup.cs files are essential for running the application:

Program.cs : serves as the entry point, responsible for configuring the web host and the request pipeline.

In .NET 5 and older versions:

public class Program {
    public static void Main(string[] args) {
      CreateHostBuilder(args).Build().Run();
    }

    public static IHostBuilder CreateHostBuilder(string[] args) => Host.CreateDefaultBuilder(args)
        .ConfigureWebHostDefaults(webBuilder => {
          webBuilder.UseStartup<Startup>(); // References Startup.cs
        });
    }

Starting from .NET 6, there is no longer a need to explicitly configure the Main() method due to the introduction of the Minimal Hosting Model.

var builder = WebApplication.CreateBuilder(args); // Add services to the container.

builder.Services.AddControllers();

var app = builder.Build(); // Configure the HTTP request pipeline.

app.UseAuthorization();
app.MapControllers();

app.Run();

Startup.cs : responsible for manage services, middlewares, and request handling logic. Can have methods like ConfigureServices (for dependency injection and service configuration) and Configure (to define the middleware pipeline).

ConfigureServices: Used to register services for dependency injection (DI). This is where you add services like controllers, databases (Entity Framework), authentication, etc.

public void ConfigureServices(IServiceCollection services) {
    services.AddControllers();

    services.AddDbContext<ApplicationDbContext>(options =>
        options.UseSqlServer(
          Configuration.GetConnectionString("DefaultConnection")
        )
    );
}

Configure: Used to define the middleware pipeline for handling HTTP requests and responses. Middleware components are executed in the order they are added.

public void Configure(IApplicationBuilder app, IWebHostEnvironment env) {
    if (env.IsDevelopment()) {
        app.UseDeveloperExceptionPage();
    }

    app.UseRouting();

    app.UseAuthorization();

    app.UseEndpoints(endpoints => {
        endpoints.MapControllers();
    });
}

Minimal Hosting Model

After .NET 6, the differences between Program.cs and Startup.cs were reduced, and Startup.cs became optional. Therefore, all configurations can be done within Program.cs, and Startup.cs does not need to exist in the project.

However, there are scenarios where using Startup.cs is still common, such as migrating from older versions of ASP.NET Core or in large-scale applications for better organization.

2. Request Initialization

The Kestrel server, a built-in webhost server from ASP.NET, listens for HTTP requests and initiates the middleware pipeline configured in either Startup.cs or Program.cs.

It’s possible to use other webhost servers, like IIS.

3. Request Handling by Middleware Pipeline

ASP.NET Core depends on middleware to manage requests, such as authentication, routing, static file handling, session management, error processing, and logging. Middleware is processed in sequence as defined in the application.

Examples:

1. Authentication: Authenticates the request (e.g., cookie-based, JWT).
2. Routing: Determines how to map the request to specific endpoints.
3. Static Files: Handles serving static files like CSS, JavaScript, and images.
4. Session Management: Handles sessions if session state is required.
5. Error Handling: Catches and processes unhandled exceptions.
6. Logging: Middleware logs requests and errors.

In this pipeline are your customized middlewares.

4. Routing

The routing middleware directs incoming requests to the correct endpoint (e.g., controller actions). It plays a pivotal role in ensuring the request reaches the right resource.

5. Action Execution

Once the route is matched, the appropriate action method in the controller is executed, handling the request and preparing the necessary response.

6. Response Generation

After processing the request, a result (e.g., JSON or HTML) is generated and prepared to be sent back to the client.

7. Middleware Post-Processing

As the response travels back through the middleware pipeline, additional operations like logging and exception handling are performed.

8. End Request

The response is sent to the client, closing the connection, and any necessary cleanup tasks are carried out.

9. Application Shutdown

During shutdown (whether planned or due to failure), services and resources are gracefully released and disposed of.

Conclusion

Mastering the lifecycle of an ASP.NET Core API is essential for developers to create scalable, high-performance, and secure applications. Knowing how requests flow through the system helps with debugging, optimizing performance, and maintaining code effectively. This knowledge equips developers to anticipate issues, quickly find and fix bugs, and apply best software development practices. Ultimately, it enables the development of intelligent, resilient, and maintainable applications.
